ACTIVE
Architecture |
Voltage FB |
Number of channels |
2 |
Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V) |
2.7 |
Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V) |
5.4 |
GBW (typ) (MHz) |
20 |
BW at Acl (MHz) |
50 |
Acl, min spec gain (V/V) |
1 |
Slew rate (typ) (V/µs) |
26 |
Vn at flatband (typ) (nV√Hz) |
12 |
Vn at 1 kHz (typ) (nV√Hz) |
12 |
Iq per channel (typ) (mA) |
0.17 |
Vos (offset voltage at 25°C) (max) (mV) |
1.9 |
Rail-to-rail |
In to V-, Out |
Rating |
Catalog |
Operating temperature range (°C) |
-40 to 125 |
CMRR (typ) (dB) |
104 |
Input bias current (max) (pA) |
90000 |
Offset drift (typ) (µV/°C) |
1.2 |
Iout (typ) (mA) |
20 |
2nd harmonic (dBc) |
131 |
3rd harmonic (dBc) |
146 |
Frequency of harmonic distortion measurement (MHz) |
0.01 |
VSSOP (DGK)-8-14.7 mm² 3 x 4.9
The OPA2834 is a dual-channel, ultra-low-power, rail-to-rail output, negative-rail input, voltage-feedback (VFB) operational amplifier designed to operate over a power-supply range of 2.7 V to 5.4 V with a single supply, or ±1.35 V to ±2.7 V with a dual supply. Consuming only 170 µA per channel and with a unity-gain bandwidth of 50 MHz, this amplifier sets an industry-leading performance-to-power ratio for rail-to-rail amplifiers.
For battery-powered and portable applications where low power consumption is of key importance, the OPA2834 offers an excellent bandwidth to IQ ratio. OPA2834 offers very low distortion making it very suitable for data acquisition systems and microphone pre-amplifier.
See the Device Comparison Table for a selection of low-power, low-noise, 5-V amplifiers from Texas Instruments with a gain-bandwidth product from 20 MHz to 300 MHz.
