- Operates from ±5V to ±18V Supplies
- Less Than 10 μs Acquisition Time
- TTL, PMOS, CMOS Compatible Logic Input
- 0.5 mV Typical Hold Step at Ch = 0.01 μF
- Low Input Offset
- 0.002% Gain Accuracy
- Low Output Noise in Hold Mode
- Input Characteristics Do Not Change During Hold Mode
- High Supply Rejection Ratio in Sample or Hold
- Wide Bandwidth
- Space Qualified
Logic Inputs on the LF198 are Fully Differential with Low Input Current, Allowing Direct Connection to TTL, PMOS, and CMOS. Differential Threshold is 1.4V. The LF198 will Operate from ±5V to ±18V Supplies.
