DLP160AP
  • DLP160AP

DLP160AP

ACTIVE

0.16-inch QnHD DLP® digital micromirror device (DMD)

Texas Instruments DLP160AP Product Info

1 April 2026 3

Parameters

Display resolution (max)

QnHD (320x180)

System brightness (max) (lm)

120

Input frame rate (max) (Hz)

60

Array diagonal (in)

0.16

Micromirror array size

640x360

Micromirror pitch (mm)

0.0054

Chipset family

DLP160AP, DLPA2000, DLPA2005, DLPC3420

Rating

Catalog

Operating temperature range (°C)

0 to 70

Package

DLP-S248 (FQT)-42-66.5483 mm² 13.39 x 4.97

Features

  • Ultra-compact 0.16-inch (3.965-mm) diagonal micromirror array
    • Displays 320 × 180 resolution
    • 5.4 µm micromirror pitch
    • 17° micromirror tilt (relative to flat surface)
    • Side illumination for optimal efficiency and optical engine size
    • Polarization independent aluminum micromirror surface
  • 4-Bit SubLVDS input data bus
  • Dedicated DLPC3420 display controller and DLPA2000 or DLPA2005 PMIC/LED driver for reliable operation
  • Ultra-compact 0.16-inch (3.965-mm) diagonal micromirror array
    • Displays 320 × 180 resolution
    • 5.4 µm micromirror pitch
    • 17° micromirror tilt (relative to flat surface)
    • Side illumination for optimal efficiency and optical engine size
    • Polarization independent aluminum micromirror surface
  • 4-Bit SubLVDS input data bus
  • Dedicated DLPC3420 display controller and DLPA2000 or DLPA2005 PMIC/LED driver for reliable operation

Description

The DLP160AP digital micromirror device (DMD) is a digitally controlled micro-opto-electromechanical system (MOEMS) spatial light modulator (SLM). When coupled to an appropriate optical system, the DLP160AP DMD displays a crisp and high-quality image or video. DLP160AP is part of the chipset comprising the DLP160AP DMD and DLPC3420 controller. This chipset is also supported by the DLPA2000 or DLPA2005 PMIC/LED driver. The compact physical size of the DLP160AP is well-suited for portable equipment where small form factor and low power is important. The compact DLP160AP DMD coupled with the controller and PMIC/LED driver provides a complete system solution that enables small form factor, low power, and high image quality displays.
