LT7200S

RECOMMENDED FOR NEW DESIGNS

18V, Quad ±5A/ Quad Phase ±20A Silent Switcher®2 Step-Down Regulator

Analog Devices LT7200S Product Info

10 February 2026 6

Features

Silent Switcher 2 Architecture:
- Ultralow EMI
- Eliminated PCB Layout Sensitivity
- Internal Bypass Caps Reduce Radiated EMI
SV_IN Range: 2.9V to 18V; PV_IN: 1.5V to 18V
Wide V_OUT Range: 0.5V to 0.9V_IN
Output Current: ±20A (±5A per Channel)
Accurate Reference: 0.5V ± 0.8% Over Temp
High Efficiency: Up to 96%
12ns Min on-time: True 12V to 1V at 2MHz
Programmable Multi-phase, Synchronizable Frequency: 400kHz to 3MHz

Current Mode: Excellent Line and Load Transient Response
User Selectable Discontinuous Mode^® (DCM) or Forced Continuous Mode (FCM) Operation
Flexible Individual Internal Compensation for Ease of Use; External for Fast Transient
Accurate Individual 1.2V EN/ Run Pin Threshold
Individual Output Tracking and Soft-Start
Individual Power Good Status Output
Low Profile 5mm x 6mm 48-Lead LQFN Package
AEC-Q100 Qualified for Automotive Applications

Part details & applications

The LT7200S is a quad-channel, high efficiency monolithic synchronous buck regulator, capable of sinking/sourcing 5A to the load per channel. Its multichannel flexibility is ideal for powering complex systems with the compact layout. The operating supply voltage range is from 2.9V to 18V, making it suitable for various supply applications from a 3.3V, 5V to 12V supply.

The operating frequency is programmable from 400kHz to 3MHz with an external resistor, or externally synchronized for switching noise sensitive applications. The unique “phase lockable, controlled on-time, constant frequency, current mode” architecture, is ideal for high frequency, high stepdown applications while demanding fast transient responses. The high frequency capability allows smaller surface mount inductors and capacitors. The MODE/SYNC pin selects low noise Forced Continuous Mode (FCM) or high efficiency Discontinuous Mode (DCM). The PHMODE pin allows to run out-of-phase among 4 channels, which lessens the required input and output capacitors. The LT7200S uses second generation Silent Switcher technology with integrated bypass capacitors to deliver a highly efficient solution at high frequencies with excellent EMI performance.

Applications

Distributed Power Systems, Server Power
Point of Load Supply for ASIC, FPGA, Etc.
