ACTIVE
Configuration |
2:1 SPDT |
Number of channels |
4 |
Power supply voltage - single (V) |
1.8, 2.5, 3.3 |
Protocols |
Analog |
Ron (typ) (Ω) |
5.5 |
CON (typ) (pF) |
16 |
ON-state leakage current (max) (µA) |
2 |
Supply current (typ) (µA) |
0.7 |
Bandwidth (MHz) |
300 |
Operating temperature range (°C) |
-40 to 85 |
Input/output continuous current (max) (A) |
0.064 |
Rating |
Catalog |
Drain supply voltage (max) (V) |
3.6 |
Supply voltage (max) (V) |
3.6 |
SOIC (D)-16-59.4 mm² 9.9 x 6
The TS3A5018 device is a quad single-pole double-throw (SPDT) analog switch that is designed to operate from 1.8 V to 3.6 V. This device can handle digital and analog signals, and signals up to V+ can be transmitted in either direction.
