• Low Supply-Voltage Range, 1.8 V to 3.6 V
• Ultralow-Power Consumption:
  • Active Mode: 400 µA at 1 MHz, 2.2 V
  • Standby Mode: 1.3 µA
  • Off Mode (RAM Retention): 0.22 µA
• Five Power-Saving Modes
• Wake-Up From Standby Mode in Less Than 6 µs
• 16-Bit RISC Architecture, Extended Memory, 125-ns Instruction Cycle Time
• Three Channel Internal DMA
• 12-Bit A/D Converter With Internal Reference, Sample-and-Hold and Autoscan
  Feature (MSP430x461x only)
• 16-Bit Timer_A With Three Capture/Compare Registers
• 16-Bit Timer_B With Seven Capture/Compare-With-Shadow Registers
• On-Chip Comparator
• Supply Voltage Supervisor/Monitor With Programmable Level Detection
• Basic Timer With Real Time Clock Feature
• Integrated LCD Driver up to 160 Segments With Regulated Charge Pump
• Serial Communication Interface (USART1), Select Asynchronous UART or
  Synchronous SPI by Software
• Universal Serial Communication Interface
  • Enhanced UART Supporting Auto-Baudrate Detection
  • IrDA Encoder and Decoder
  • Synchronous SPI
  • I2C™
• Serial Onboard Programming, Programmable Code Protection by Security Fuse
• Brownout Detector
• Family Members Include:
  • MSP430x4616, MSP430x46161⁽¹⁾:
    • 92KB+256B Flash or ROM Memory
    • 4KB RAM
  • MSP430x4617, MSP430x46171⁽¹⁾:
    • 92KB+256B Flash or ROM Memory
    • 8KB RAM
  • MSP430x4618, MSP430x46181⁽¹⁾:
    • 116KB+256B Flash or ROM Memory
    • 8KB RAM
  • MSP430x4619, MSP430x46191⁽¹⁾:
    • 120KB+256B Flash or ROM Memory
    • 4KB RAM
• For Complete Module Descriptions, Refer to the MSP430x4xx Family User’s Guide

⁽¹⁾ The MSP430F461x1 devices are identical to the MSP430F461x devices, with the exception that the ADC12 module is not implemented.
