DLP472NP
  • DLP472NP
  • DLP472NP

DLP472NP

ACTIVE

0.47-inch 1080p DLP® digital micromirror device (DMD)

Texas Instruments DLP472NP Product Info

1 April 2026 3

Parameters

Display resolution (max)

1080p (1920x1080)

System brightness (max) (lm)

1800

Input frame rate (max) (Hz)

240

Array diagonal (in)

0.47

Micromirror array size

1920x1080

Micromirror pitch (mm)

0.0054

Chipset family

DLP472NP, DLPA3082, DLPA3085, DLPC8444

Rating

Catalog

Operating temperature range (°C)

0 to 70

Package

DLP-S321 (FQY)-174-269.5 mm² 24.5 x 11

Features

  • 0.47-inch diagonal micromirror array
    • 1080p FHD (1920 × 1080) display resolution
    • 5.4µm micromirror pitch
    • ±17° micromirror tilt (relative to the flat surface)
    • Bottom illumination
  • SubLVDS input data bus
  • Supports 1080p up to 240Hz
  • Laser or LED operation supported by the DLPC8444 display controller and the DLPA3085 or DLPA3082 power management IC (PMIC) and LED driver
  • 0.47-inch diagonal micromirror array
    • 1080p FHD (1920 × 1080) display resolution
    • 5.4µm micromirror pitch
    • ±17° micromirror tilt (relative to the flat surface)
    • Bottom illumination
  • SubLVDS input data bus
  • Supports 1080p up to 240Hz
  • Laser or LED operation supported by the DLPC8444 display controller and the DLPA3085 or DLPA3082 power management IC (PMIC) and LED driver

Description

The DLP472NP digital micromirror device (DMD) is a digitally controlled micro-electro-mechanical system (MEMS) spatial light modulator (SLM) that enables bright 1080p FHD display systems. The TI DLP products 0.47-inch 1080p FHD chipset comprises the DLP472NP DMD, the DLPC8444 display controller, and the DLPA3085 or DLPA3082 PMIC and illuminator driver. The compact physical size of the chipset provides a complete system solution that enables small form factor 1080p FHD displays.
