0
ACTIVE
Rating |
Automotive |
VO (V) |
2.048 |
Initial accuracy (max) (%) |
0.5 |
Iz for regulation (min) (µA) |
41 |
VO adj (min) (V) |
2.048 |
VO adj (max) (V) |
2.048 |
Reference voltage (V) |
Fixed |
Temp coeff (max) (ppm/°C) |
50 |
Operating temperature range (°C) |
-40 to 125 |
Iout/Iz (max) (mA) |
20 |
SOT-23 (DBZ)-3-6.9204 mm² 2.92 x 2.37
The TL4050-Q1 family of shunt voltage references are versatile easy-to-use references designed for a wide array of applications. The two-terminal fixed-output device requires no external capacitors for operation and is stable with all capacitive loads. Additionally, the reference offers low dynamic impedance, low noise, and low temperature coefficient to maintain a stable output voltage over a wide range of operating currents and temperatures.
The TL4050-Q1 is available in three initial tolerances, ranging from 0.1% (maximum) for the A grade to 0.5% (maximum) for the C grade. Thus, a great deal of flexibility is available to designers in choosing the best cost-to-performance ratio for an application. Packaged in the space-saving SOT-23-3 and SC-70 packages and requiring a minimum current of 45µA (typical), the TL4050-Q1 also is designed for portable applications.
The TL4050x-Q1 characterization is for operation over an ambient temperature range of –40°C to 125°C.
