ACTIVE
Technology family |
LVC |
Supply voltage (min) (V) |
1.65 |
Supply voltage (max) (V) |
5.5 |
Number of channels |
1 |
IOL (max) (mA) |
32 |
IOH (max) (mA) |
-32 |
Supply current (max) (µA) |
10 |
Input type |
Standard CMOS |
Output type |
Push-Pull |
Features |
Balanced outputs, Over-voltage tolerant inputs, Unbuffered, Very high speed (tpd 5-10ns) |
Rating |
Automotive |
Operating temperature range (°C) |
to |
SOT-SC70 (DCK)-5-4.2 mm² 2 x 2.1
AEC-Q100 qualified for automotive applications:
Device temperature grade 1: -40°C to +125°C
The SN74LVC1GU04-Q1 is a single channel unbuffered CMOS inverter.
Unbuffered inverters contain a single CMOS inverter stage and can be operated both in standard digital switching applications and in the analog linear region. While primarily specified for digital operation, the unbuffered architecture supports potential analog applications such as crystal oscillator circuits or linear amplification.
