0
Active and preferred
A/D Input Lines (incl. FADC) |
12 |
Additional Features |
Special purpose timer CCU8, 4x ACMP, BCCU, MATH co-processor, POSIF |
Budgetary Price €/1k |
1.43, 1.43 |
CPU |
ARM Cortex-M0 |
Digital I/O Pins |
55 |
DMA Channels |
0 |
DSP Functionality |
No |
EEPROM Emulation |
Yes |
External Bus Interface |
No |
Family |
XMC1400 |
Fast Flash Programming |
No |
Flash |
200 kByte |
Floating Point Unit |
No |
Frequency max |
48 MHz |
I/O Operation Voltages |
1.8 V, 5.5 V |
Instruction Width ([bits]) |
32/16 |
Number of ADC Modules |
2 |
On-chip Clock Generation |
Yes |
On-chip Voltage Regulator |
Yes |
Oscillator Watchdog |
Yes |
Power Mode |
clock gating possible |
Program Memory |
200 kByte |
Qualification |
Industrial |
Real Time Clock |
Yes |
Secondary Core |
N/A |
Serial I/O Interfaces |
4 |
SRAM (incl. Cache) |
16 kByte |
SRAM |
16 kByte |
Temperature |
-40 to 105°C |
Timed I/O Pins (PWM, CAPCOM) |
25 |
Timer/Counter |
16 |
Touch/LED Matrix Control |
No |
Type of Memory |
Flash |
Type of Serial I/O Interfaces |
I²S, I²C, SPI, UART |
Watchdog Timer |
Yes |
Light electric vehicle solutions, Complete system solutions for smart TVs, DIN rail power supply solutions, Residential air conditioning
