IRS2453DS
  • IRS2453DS

IRS2453DS

Active and preferred

EiceDRIVER™ 600 V full-bridge Gate Driver IC with typical 0.18 A source and 0.26 A sink currents in 14-Lead SOIC package for IGBTs and MOSFETs . Also available in 14-Lead PDIP. It also includes latched and non-latched shutdown pins.

Infineon Technologies IRS2453DS Product Info

16 April 2026 0

Parameters

Channels

4

Configuration

Full Bridge

Input Vcc min

10.1 V

Isolation Type

Functional levelshift JI (Junction Isolated)

Output Current (Sink)

0.26 A

Output Current (Source)

0.18 A

Product Name

IRS2453DS

Qualification

Industrial

VBS UVLO (Off)

8 V

VBS UVLO (On)

9 V

VCC UVLO (Off)

9 V

VCC UVLO (On)

11 V

Voltage Class

600 V

Apps

LED lighting system design, 1-phase string inverter solutions

Features

  • Integ. 600 V full-bridge driver
  • CT, RT programmable oscillator
  • 15.6 V Zener clamp on Vcc
  • Micropower startup
  • Logic level latched shutdown pin
  • Non-latched shutdown on CT pin
  • Internal bootstrap FETs
  • Excellent latch immunity
  • ESD protection on all pins
  • 14-lead SOIC
  • 1 μs (typ.) internal dead time
  • RoHS compliant
