0
Active and preferred
Country of Assembly (Last BE site, current, subject to change) |
Malaysia |
Country of Diffusion (Last FE site, current, subject to change) |
Austria, Germany |
ID (@25°C) max |
165 A |
IDpuls max |
660 A |
Launch year |
2018 |
Operating Temperature range |
-55 °C to 175 °C |
Package |
TOLG (PG-HSOG-8) |
Planned to be available until at least |
2038 |
Polarity |
N |
Ptot max |
167 W |
QG (typ @10V) |
70 nC |
QG (typ @10V) max |
90 nC |
Qualification |
Automotive |
RDS (on) (@10V) max |
2.9 mΩ |
RthJC max |
0.9 K/W |
Technology |
OptiMOS™5 |
VDS max |
80 V |
VGS(th) range |
2.2 V to 3.8 V |
VGS(th) |
3 V |
