Analog Devices MAX25014 Product Info

• Wide Voltage-Range Operation
  • Operates Down to 2.5V Supply After Startup
  • Survives Load Dumps Up to 40V
• High Integration
  • Complete 4-Channel Solution Including Boost Controller
  • I²C Control for Minimum Parts Count
• Robust and Low EMI
  • Spread-Spectrum Oscillator
  • Phase Shifting
  • 400kHz to 2.2MHz Switching-Frequency Range
  • nMOS Input Protection Switch
• Multiple Diagnostic Features
  • LED-Current Measurement
  • Boost Output Voltage Measurement
  • LED Open/Short Detection and Protection
  • Boost Output Undervoltage and Overvoltage
• Versatile Dimming Scheme Allows Hybrid or PWM-Only Dimming Using DIM Input or I²C
  • Dimming Ratio > 10,000:1 Using Hybrid Dimming
  • 10,000:1 Dimming Ratio at 200Hz Using PWM Dimming
• Compact (4mm x 4mm) 24-Pin TQFN and SWTQFN Packages

The MAX25014 is a 4-channel backlight driver IC with boost controller for automotive displays. The integrated current outputs can sink up to 150mA LED current each. The device accepts a wide 2.5V to 36V input volt­age range and withstands automotive load-dump events.

The internal current-mode switching DC-DC controller supports boost or SEPIC topologies and operates in the 400kHz to 2.2MHz frequency range. Integrated spread spectrum helps reduce EMI. An adaptive output-voltage-control scheme minimizes power dissipation in the LED current-sink paths.

Control is included for an external nMOSFET series switch to reduce quiescent current when the backlight is off and to disconnect the boost converter in the case of a fault.

The device features I²C-controlled pulse-width-modu­lation (PWM) dimming and hybrid dimming. In either case, the minimum pulse width is 500ns. Phase-shifted dimming of the strings is incorporated for lower EMI.

The MAX25014 is available in a 24-pin TQFN or 24-pin side-wettable TQFN (SWTQFN) package and operates over the -40°C to +125°C temperature range.

Applications

• Central Information Displays
• Infotainment Displays
• Instrument Clusters
