DS1091L

PRODUCTION

Automotive Temperature Range Spread-Spectrum EconOscillator™ Industry's Only 3V All-Silicon Center Spread Clock Generator to Reduce EMI in the Automotive Temperature Range

Analog Devices DS1091L Product Info

10 February 2026 4

Features

Spread-Spectrum Clock Output from 130kHz to 66.6MHz
-40°C to +125°C Operating Temperature Range
±1.75% Accuracy Across Temperature and Voltage
Factory Trimmed
Center-Dithered (DS1091LUA) or Down-Dithered (DS1091LUB) Spread-Spectrum Output
Pin-Selectable Center-Dither Magnitude of 0%, ±1%, ±2%, or ±4%
Pin-Selectable Down-Dither Magnitude of 0%, -2%, -4%, or -8%
Pin-Selectable Dither Rate
3.0V to 3.6V Supply Operation
Lead-Free, 8-Pin µMAX Package

Part details & applications

The DS1091L is a low-cost clock generator that is factory-trimmed to output frequencies from 130kHz to 66.6MHz with a nominal accuracy of ±0.25%. The device can also produce a center- or down-dithered spread-spectrum output with pin-selectable dither magnitude and rate. Assembled in an 8-pin µMAX^® package, the DS1091L is designed to operate with a 3.0V to 3.6V power supply over the automotive temperature range (-40°C to +125°C).

Applications

Automotive Infotainment
Industrial Control
LCD Displays
POS Terminals
Printers
