ADV7382

RECOMMENDED FOR NEW DESIGNS

Car Camera Bus Receiver with MIPI CSI-2 Video Output

Analog Devices ADV7382 Product Info

10 February 2026 5

Features

Car camera bus (C²B) receiver capable of receiving video data and bidirectional control data over a differential pair or single-ended cable
The ADV7382 features a mobile industry processor interface (MIPI) camera serial interface-2 (CSI-2) transmitter supporting
- 2-lane operation at up to 1 Gbps per lane
- 1-lane operation at up to 1 Gbps
HD video formats supported up to 2 megapixels at 30 Hz or 1 megapixel at 60 Hz
Bidirectional control channel embedded in the C²B link for control and status data between the C²B receiver and the C²B transmitter
Enables remote configuration of the C²B transmitter
Bidirectional GPIO with either local or remote interfacing possibilities
On-chip high resolution, high speed analog-to-digital converter (ADC), buffer and anti-aliasing filter blocks for video and control channel path
Transmission of frame count data from ISP to enable the back-end electronic camera unit (ECU) or the head unit (HU) to detect stuck or skipped frames
Video test pattern generator for simplified system testing Cable equalizer capable of compensating for cable and connector insertion loss, equivalent to a 30 m twisted pair cable

On-chip echo cancellation scheme to prevent visual impact caused by impedance mismatch between cables and connectors
Protection from and diagnosis of high voltages encountered during short to battery fault condition
Tested to industry standards for automotive electromagnetic compatibility (EMC), electromagnetic interference (EMI), and electrostatic discharge (ESD) robustness
General

Part details & applications

Complete technical specifications are available for the C²B transmitters and receivers. Contact [email protected] to complete the nondisclosure agreement (NDA) required to receive additional product information.
