ADRF5048

RECOMMENDED FOR NEW DESIGNS

Silicon SP4T Switch, Nonreflective, 100 MHz to 45 GHz

Analog Devices ADRF5048 Product Info

10 February 2026 5

Features

Ultrawideband frequency range: 100 MHz to 45 GHz
Nonreflective 50 Ω design
Low insertion loss

1.4 dB at 18 GHz typical
2.4 dB at 40 GHz typical
4.0 dB to 45 GHz typical

High isolation

41 dB at 18 GHz typical
35 dB at 40 GHz typical
35 dB at 45 GHz typical

High input linearity

P0.1dB: >30 dBm typical
IP3: 52 dBm typical

High power handling

30 dBm through path
18 dbm terminated path

No low frequency spurious
ESD ratings

±1000 V for RFx pins
±2000 V for supply and digital control pins

CDM: ±500 V for all pins

On and off time (50% V_CTRL to 90% of final RF_out): 20 ns
RF settling time (50% V_CTRL to 0.1 dB of final RF_out): 60 ns
3 mm x 3 mm, 24-terminal LGA package
Pin compatible with the ADRF5049, ADRF5042 and ADRF5043

Part details & applications

The ADRF5048 is a nonreflective SP4T switch manufactured in the silicon on insulator (SOI) process.

This device operates from 100 MHz to 45 GHz with an insertion loss lower than 4.0 dB and isolation higher than 35 dB. The ADRF5048 has an RF input power handling capability of 30 dBm through path, 18 dBm terminated path, and 30 dBm hot switching at the RF common port.

The ADRF5048 requires a dual-supply voltage of +3.3 V and −3.3 V. The device employs complimentary metal-oxide semiconductor (CMOS)-/low-voltage transistor to transistor logic (LVTTL) logic-compatible controls.

The ADRF5048 has enable and logic select controls to feature all off state and mirror port selection, respectively.

The ADRF5048 is pin compatible with the ADRF5049, ADRF5042 and ADRF5043.

The ADRF5048 comes in a 24-terminal, 3 mm × 3 mm, RoHS compliant, land grid array (LGA) package and can operate from −40°C to +105°C.

APPLICATIONS

Industrial scanners

Test instrumentation

Cellular infrastructure—mmWave 5G

Military radios, radars, and electronic counter measures (ECMs)

Microwave radios and very small aperture terminals (VSATs)
