AD5310R

PRODUCTION

10-Bit nano DAC, SPI Interface and 2 ppm /°C On-Chip Reference

Analog Devices AD5310R Product Info

10 February 2026 6

Features

High relative accuracy (INL): ±0.5 LSB maximum
Low drift 2.5 V reference: 2 ppm/°C typical
Selectable span output: 2.5 V or 5 V
Total unadjusted error (TUE): 0.06% of FSR maximum
Offset error: ±1.5 mV maximum
Gain error: ±0.05 % of FSR maximum

Low glitch: 0.1 nV-sec
High drive capability: 20 mA
Low power: 1.2 mW at 3.3 V
Independent logic supply: 1.8 V logic compatible
Wide operating temperature range: −40°C to +105°C
Robust 4 kV HBM ESD protection

Part details & applications

The AD5310R / AD5311R, members of the nanoDAC^® family, are low power, single-channel, 10-bit buffered voltage-out DACs. The devices include an enabled by default internal 2.5 V reference, and provides 2 ppm/°C. The output span can be programmed to be 0 V to V_REF or 0 V to 2 × V_REF. All devices operate from a single 2.7 V to 5.5 V supply and are guaranteed monotonic by design. The devices are available in 10-lead MSOP packages.

The internal power-on reset circuit of the AD5310R/AD5311R ensures that the DAC register is written to zero scale at powerup when the internal output buffer is configured in normal mode. The devices contain a power-down mode that reduces the current consumption of the device to 2 µA at 5 V.

The AD5310R / AD5311R use a versatile SPI or I²C interface, including an asynchronous RESET pin and a V_LOGIC pin, allowing 1.8 V compatibility.

Product Highlights

High Relative Accuracy (INL): ±0.5 LSB maximum.
Low Drift 2.5 V On-Chip Reference: 5 ppm/°C maximum temperature coefficient.

Applications

Process controls
Data acquisition systems
Digital gain and offset adjustment
Programmable voltage sources
Optical modules
