ADRF5047

RECOMMENDED FOR NEW DESIGNS

Silicon SP4T Switch, Reflective, 9 kHz to 44 GHz

Analog Devices ADRF5047 Product Info

10 February 2026 5

Features

Ultrawideband frequency range: 9 kHz to 44 GHz
Reflective design
Low insertion loss
- 1.5 dB to 18 GHz
- 2.4 dB to 40 GHz
- 2.7 dB to 44 GHz
High isolation
- 47 dB to 18 GHz
- 33 dB to 40 GHz
- 31 dB to 44 GHz

High input linearity
- P0.1dB: 26.5 dBm typical
- IP3: 50 dBm typical
High RF input power handling
- Through path: 26 dBm
- Hot switching: 26 dBm
No low frequency spurious
0.1 dB RF settling time: 5.2 μs
20-terminal, 3 mm × 3 mm, RoHS-compliant, LGA package
Pin compatible with ADRF5046, fast switching version

Part details & applications

The ADRF5047 is a reflective, single-pole, four-throw (SP4T) switch manufactured in the silicon process.

The ADRF5047 operates from 9 kHz to 44 GHz with an insertion loss of lower than 2.7 dB and isolation of higher than 31 dB. The device has a radio frequency (RF) input power handling capability of 26 dBm for both through path and hot switching at RFC.

The ADRF5047 draws a low current of 3 μA on the positive supply of +3.3 V, and −110 μA on the negative supply of −3.3 V. The device provides complementary metal-oxide semiconductor (CMOS)-/low voltage transistor-transistor logic (LVTTL)-compatible controls.

The ADRF5047 is pin-compatible with the ADRF5046, fast switching version, which operates from 100 MHz to 44 GHz.

The ADRF5047 comes in a 20-terminal, 3 mm × 3 mm, RoHS-compliant, land grid array (LGA) package and can operate from −40°C to +105°C.

Applications

Industrial scanner
Test instrumentation
Cellular infrastructure—mmWave 5G
Military radios, radars, and electronic counter measures (ECMs)
Microwave radios and very small aperture terminals (VSATs)
