ADGS1414D
  • ADGS1414D
  • ADGS1414D

ADGS1414D

RECOMMENDED FOR NEW DESIGNS

SPI, 1.5 Ω RON, ±15 V/±5 V/+12 V, High Density Octal SPST Switch

Analog Devices ADGS1414D Product Info

10 February 2026 6

Features

  • SPI with error detection
    • Includes CRC, invalid read and write address, and SCLK count error detection
    • Supports burst mode and daisy-chain mode
    • Industry-standard SPI Mode 0 and Mode 3 interface compatible
  • Integrated passive components
  • Route through of digital signals and supplies
  • Guaranteed break-before-make switching allowing external wiring of switches to deliver multiplexer configurations
  • 1.5 Ω typical on resistance at 25°C (±15 V dual supply)
  • 0.3 Ω typical on resistance flatness at 25°C (±15 V dual supply)
  • 0.1 Ω typical on resistance match between channels at 25°C (±15 V dual supply)
  • VSS to VDD analog signal range
  • Fully specified at ±15 V, ±5 V, and +12 V
  • 1.8 V logic compatibility with 2.7 V ≤ VL ≤ 3.3 V (excludes SPI readback to a 1.8 V device)
  • 4 mm × 5 mm, 30-terminal LGA

Part details & applications

The ADGS1414D contains eight independent SPST switches. A serial peripheral interface (SPI) controls the switches. The SPI has robust error detection features, such as cyclic redundancy check (CRC) error detection, invalid read and write address detection, and SCLK count error detection. It is possible to daisy-chain multiple ADGS1414D devices together. Daisy-chain mode enables the configuration of multiple devices with a minimal amount of digital lines. The route of digital signals and supplies through the ADGS1414D allows for a further increase in channel density. Integrated passive components eliminate the need for external passive components. FUNCTIONAL BLOCK DIAGRAM Figure 1. The ADGS1414D is suited to high density switching applications, such as large switching matrices and fanout applications. Each switch conducts equally well in both directions when on, and each switch has an input signal range that extends to the supplies. In the off condition, signal levels up to the supplies are blocked. Multifunction pin names may be referenced by their relevant function only.

Applications

  • Automated test equipment
  • Data acquisition systems
  • Sample-and-hold systems
  • Audio and video signal routing
  • Communications systems
  • Relay replacement
