0
ACTIVE
Technology family |
LVC |
Supply voltage (min) (V) |
1.65 |
Supply voltage (max) (V) |
3.6 |
Number of channels |
8 |
IOL (max) (mA) |
24 |
Supply current (max) (µA) |
40 |
IOH (max) (mA) |
-24 |
Input type |
Standard CMOS |
Output type |
3-State |
Features |
Balanced outputs, Very high speed (tpd 5-10ns) |
Rating |
Automotive |
Operating temperature range (°C) |
-40 to 125 |
SOIC (DW)-20-131.84 mm² 12.8 x 10.3
These octal bus buffers are designed for 1.65V to 3.6V VCC operation. The SN74LVC244A-Q1 devices are designed for asynchronous communication between data buses.
