SLC37PDZXXX
  • SLC37PDZXXX

SLC37PDZXXX

The 40nm SLC37PDx product series improves user experience with boost contactless and performance experience and offers excellent flexibility.

Infineon Technologies SLC37PDZXXX Product Info

16 April 2026 0

Parameters

Additional Information

Please note that xxx stands for NVM size, z – different interfaces

Ambient Temperature range

-25 °C to 85 °C

Applications

wearables payment , multiapplication

Asymmetric Cryptography

ECC up to 521-bit, RSA up to 4096-bit

Certifications

CC EAL6+ high targeted, CUP (targeted), EMVCo (targeted)

CPU

32-bit Arm® SecurCore® SC300

Delivery Forms

6/8 pin dual-interface modules and contactless modules, sawn wafer, Coil on Module

Interfaces

optional NRG™ (ISO/IEC 14443-3 type A with CRYPTO1), ISO 7816, ISO 14443 A/B, ISO 18092 passive mode, optimized for small antenna sizes

Leading Technologies

Coil on Module, SOLID FLASH™

NVM range

400 kByte to 512 kByte

Product Description

dual-interface security cryptocontroller for multiapplication and wearables payment use cases supporting multi-interface

RAM

14 kByte

Symmetric Cryptography

DES, 3DES, AES up to 256-bit

Features

  • High-performance 32-bit CPU based on Arm® SecurCore® SC300 enhanced  by  Infineon Technologies’ cache security concept
  • Up to 512 KB SOLID FLASH™ NVM with free partitioning code/data and up to 16 KB RAM
  • Supporting interfaces: ISO14443 Type A/B & ISO18092 (NFC) contactless, ISO7816 contact based
  • EMVco and CC EAL 6+ certified
  • Certified efficient SW libraries for asymmetric (RSA, ECC) and symmetric (AES, 3DES) cryptography
  • CIPURSE™ crypto library upon request
  • ISS: Instruction Stream Signature for execution integrity

Description

  • Optimize time-to-market: Customers can benefit from fastest design-in of the SLC36PDx 40nm product series, as it supports wide range of applications from the smallest to most powerful chip in the market. R&D resources can be optimized.
  • Excellence in converging markets: The state of the art Arm® SecurCore® SC300 chip architecture of the 40nm SLC36PDx product series enables a CL boost performance for high demanding payment and multi-application uses cases.
  • Best fit for all regional variances: The product offering is designed for global markets and support specific regional market requirements. The excellent Infineon customer support within the regional organization around the globe enables a very fast time to market.
  • Innovations platform: The 40nm platform and its enhanced feature enables innovations, including market trends such as biometric authentication. Innovative ready to use delivery forms such as the SPA modules enable very fast design of new form factors within a few weeks.
