Active and preferred
A/D Input Lines |
1 |
ADC (#, Max. Resolution @ Sample Rate) |
SAR (1, 12-20 bit @ 5 msps) |
Additional Features |
Helium DSP, NNLite NPU, EPC2 Security, 2.5D GPU |
BLE Maximum Data Rate |
N/A |
BLE Power Output |
N/A |
BLE RX Sensitivity |
N/A |
BLE Supported Frequency band |
N/A |
CAN |
2 |
CapSense |
N |
Communication Interfaces |
I2C, SPI, UART |
Comparators |
2 |
CPU |
ARM Cortex-M55 |
Cryptographics Accelerator |
Y |
DAC (#, Max. Resolution @ Sample Rate) |
(2,12-bit) |
Development Software |
ModusToolbox™ |
DMA Channels |
32 |
Family |
PSOC Edge E82 |
Floating Point Unit |
Y |
Frequency |
400 MHz |
I/O Pins (Smart) range |
16 to 147 |
I2S |
2 |
LCD Direct Drive |
N |
Lead Ball Finish |
Sn/Ag/Cu |
Number of ADC Modules |
1 |
Operating Temperature max |
70 °C |
Operating Temperature min |
-20 °C |
Operating Voltage range |
1.71 V to 3.6 V |
Operational Amplifier |
4 |
PDM-PCM |
6 |
Peak Reflow Temp |
260 °C |
Quad-SPI |
2 |
Qualification |
Commercial |
Real Time Clock |
Y |
Secondary Core |
ARM Cortex-M33 |
Serial Communication Blocks |
12 |
SRAM |
2048 kByte |
Timer/Counter/PWM Blocks |
32 |
Universal Digital Blocks |
0 |
USB I/O |
2 |
USB Type |
USB 2.0 HS/FS |
