Active and preferred
Channels |
2 |
Classification |
- |
Control Interface |
Discrete |
Diagnostics |
- |
EAS/Avalanche Energy |
150 mJ |
EAS (Energy capability) |
150 mJ |
Family |
Classic HITFET™ 12V |
ID(lim) min |
5 A |
ID |
1.3 A |
IL(nom) |
1.3 A |
IL (Short Circuit Current) |
5 A |
Load Current |
1.3 A |
Mounting |
SMT |
Nominal Load Current per channel |
1.3 A |
Operating Temperature range |
-40 °C to 150 °C |
Planned to be available until at least |
2039 |
Protection strategy |
Auto-restart |
Ptot max |
0.8 W |
RDS (on) (@ Tj = 150°C) max |
480 mΩ |
RDS (on) (@ Tj = 25°C) |
190 mΩ |
Recommended Operating Voltage max |
42 V |
toff (Turn OFF time) max |
100 µs |
ton (Turn ON time) max |
100 µs |
VDS max |
42 V |
Domain controller for ADAS & autonomous driving, Automotive body electronics & power distribution, Automotive primary power distribution unit, Automotive secondary power distribution unit, Automotive body control module (BCM)
