Channels |
1 |
Classification |
n.a |
Diagnostics |
n.a |
EAS/Avalanche Energy |
2000 mJ |
EAS (Energy capability) |
2000 mJ |
Family |
Classic HITFET™ |
Features |
24V COMPATIBLE |
ID(lim) min |
21 A |
ID |
3.8 A |
IL(LIM) min |
21 A |
IL(nom) |
3.8 A |
IL (Short Circuit Current) |
21 A |
ISC max |
64 A |
Load Current |
3.8 A |
Mounting |
THT |
Nominal Load Current per channel |
3.8 A |
Operating Temperature range |
-40 °C to 150 °C |
Planned to be available until at least |
n.a |
Protection strategy |
Latch |
Ptot max |
90 W |
RDS (on) (@ Tj = 150°C) max |
120 mΩ |
RDS (on) (@ Tj = 25°C) |
50 mΩ |
Recommended Operating Voltage max |
60 V |
toff (Turn OFF time) max |
170 µs |
ton (Turn ON time) max |
100 µs |
VDS max |
60 V |
