MAX96751

RECOMMENDED FOR NEW DESIGNS

GMSL2 Serializer with HDMI 2.0 Input

Analog Devices MAX96751 Product Info

10 February 2026 6

Features

HDMI v1.4b/v2.0a Input Interface
3Gbps or 6Gbps Forward-Link Rates
187.5Mbps Reverse-Link Rate
Full-Duplex Capability Over a Single Wire
Ideal for High-Definition Video Applications
- Up to 215MHz PCLK per Link
- Up to 430MHz PCLK in Dual-Link Mode
Uses Low-Cost 50Ω Coax or 100Ω STP Cables
Forward and Reverse I²S or 7.1 TDM Audio
Video Pattern Generator Provides Fast Link Validation
Line-Fault Monitor Detects Serial I/O Shorted Together, to Ground, to Battery or Open
ASIL-Relevant Functional Safety Features
- ASIL B Compliant
- 16-Bit CRC Protection of Control-Channel Data (I²C, UART, SPI, GPIO, Audio)
- Retransmission on Error of all Control-Channel Data and Audio Data Upon Error Detection
- Optional 32-Bit Video-Line CRC
- Selectable Interrupts for Fault Detection
- Video Watermark Generation

Performance Tools Ensure High Link Margin
- Continuous Adaptive Equalization on GMSL Links
- Built-In Forward- and Reverse-Channel PRBS Generator for BER Testing of Serial I/O Links
- Eye-Opening Monitor for Link Diagnosis
Concurrent Control Channel for Device Configuration and Communication with Remote Peripherals
- Primary and Pass-Through I²C/UART, SPI, and Tunneled or Register-Programmable GPIO
- Settable Priority Levels
- Eight Hardware Programmable Device Addresses
- Up to 20 Programmable GPIO
- Sleep Mode with Register State Retention
Operation Specified Over the -40°C to +105°C Automotive Temperature Range
AEC-Q100 Qualified
Compact 8mm x 8mm TQFN with an Exposed Pad

Part details & applications

The MAX96751 serializer converts HDMI^® to single or dual GMSL™ serial protocol. It also sends and receives side-channel and peripheral control data, enabling full-duplex, single-wire, transmission of video and bidirectional data. Each GMSL2 link operates at a fixed rate of 3Gbps or 6Gbps in the forward direction and 187.5Mbps in the reverse direction.

The MAX96751 supports RGB888 video at up to 215MHz PCLK per GMSL2 link.

For designs supporting two displays, see the New Designs Supporting Two Displays section of Detailed Descriptions for more information.

The GMSL2 concurrent control channel operates in I²C or UART mode. Two additional pass-through I²C or UART channels and a pass-through SPI channel are provided for peripheral control. The bidirectional audio channel supports I²S stereo and up to 8 channels in Time-Division Multiplexing (TDM) mode.

Data can be transmitted over low-cost 50Ω coax or 100Ω STP cables that meet the GMSL2 Channel Specification. Contact the factory to receive the GMSL2 Channel Specification document.

APPLICATIONS

Navigation and Touch-Panel Displays
Digital Instrument Clusters and Heads-Up Displays
Rear-Seat and Passenger Infotainment Displays
Consumer HDMI Port Applications
