Dual GMSL2 to CSI-2 Deserializer

Analog Devices MAX96716F Product Info

10 February 2026 5

Features

  • Full-Duplex Capability over a Single Coax or STP Cable
    • 3Gbps Forward-Link Rate
    • 187.5Mbps Reverse-Link Rate
  • Dual Four-Lane D-PHY or Dual Two-Lane C-PHY MIPI CSI-2 v1.3 Output Ports
    • Aggregation and Replication Functions
    • Support for 16 Virtual Channels
    • Supports RAW8/10/12/14/16/20, RGB565/666/888, YUV422 8-/10-Bit, User-Defined and Generic Long-Packet Data Types
  • Advanced MIPI D-PHY v1.2 Transmitters
    • 80Mbps to 2.5Gbps per Lane
    • Polarity Flip and Data-Lane Reassignment
  • Advanced MIPI C-PHY v1.0 Transmitters
    • 182Mbps to 4.56Gbps per Lane
  • ASIL-Relevant Functional-Safety Features
    • ASIL-B Compliant
    • End-to-End Data Integrity Through CRC in Tunnel Mode
    • R-S FEC for Protection of Forward Video and Control-Channel Data
    • 16-Bit CRC Protection of Side-Channel Data (I2C, UART, SPI, GPIO) with Retransmission upon Error Detection
  • 32-Bit CRC Protection of Video-Line Dat
  • Forward- and Reverse-Channel PRBS for BER Testing of Serial Link
  • Continuous Link-Margin Monitoring and Optimization
    • Forward-Channel Adaptive Equalization
    • Forward- and Reverse-Channel Eye-Opening Monitor for Continuous Link Margin Diagnosis
  • Concurrent Side-Channel for Device Configuration and Communication with Peripherals
    • I2C/UART, Pass-Through I2C/UART, SPI, GPIO, and Register-Programmable GPIO
    • Four Hardware-Programmable Device Addresses
  • Reference-over-Reverse (RoR) Channel Supports Crystal-Free Operation of Serializer
  • 48-Lead 7mm x 7mm TQFN or TQFN Side-Wettable Package with 0.5mm Lead Pitch

    • Part details & applications

    The MAX96716F converts dual GMSL2 serial inputs to MIPI CSI-2. It also transmits and receives control channel data, enabling transmission of forward-path video and bidirectional control data. The GMSL2 link operates at a fixed rate of 3Gbps in the forward direction and 187.5Mbps in the reverse direction.

    The GMSL™ inputs operate independently, allowing video with different timing and resolution to be received on each input.

    Video data from both inputs can be aggregated for output on a single CSI-2 port or replicated on a second port for redundant processing.

    The device and connected serializer are programmed through I2C or UART.

    Operation is specified over the automotive temperature range of -40°C to +105°C and the device is AEC-Q100 qualified.

    Data may be transmitted over low-cost 50Ω Coax or 100Ω STP cables that meet the GMSL2 channel specification. Contact the factory for the GMSL2 channel specification.

    Table 1. Typical Maximum Cable Length vs. Attenuation
      3.2mm Ø 50Ω Coax, Foam Dielectric 2.7mm Ø 50Ω Coax, Solid Dielectric 100Ω Shielded-Twisted Pair, AWG26
    Attenuation at 3GHz (Typ, Room Temp) 0.9dB/m 1.6dB/m
