MAX9310

PRODUCTION

1:5 Clock Driver with Selectable LVPECL Inputs and LVDS Outputs

Analog Devices MAX9310 Product Info

10 February 2026 3

Features

Guaranteed 1.0GHz Operating Frequency

8ps Output-to-Output Skew

345ps Propagation Delay

Accepts LVPECL and Differential HSTL Inputs

Synchronous Output Enable/Disable

Two Selectable Differential Inputs

2.375V to 2.625V Supply Voltage

ESD Protection: ±2kV (Human Body Model)

Input Bias Resistors Drive Output Low for Open Inputs

Part details & applications

The MAX9310 is a fast, low-skew 1:5 differential driver with selectable LVPECL/HSTL inputs and LVDS outputs, designed for clock distribution applications. This device features an ultra-low propagation delay of 345ps with 45.5mA of supply current.

The MAX9310 operates from a 2.375V to 2.625V power supply for use in 2.5V systems. A 2:1 input multiplexer is used to select one of two differential inputs. The input selection is controlled through the CLKSEL pin. This device also features a synchronous enable function.

The MAX9310 is offered in a space-saving 20-pin TSSOP package and operates over the extended temperature range from -40°C to +85°C.

Applications

Automated Test Equipment (ATE)
Central Office Backplane Clock Distribution
Data and Clock Driver and Buffer
DSLAM
Wireless Base Stations
