Analog Devices MAX8880 Product Info

• 3.5µA Supply Current at 12V
• Reverse Battery Protection
• 2.5V to 12V Input Voltage Range
• ±1.5% Output Voltage Accuracy
• 200mA max Output Current
• 2Ω PMOS Output Device
• Short-Circuit and Thermal Overload Protection
• POK Output for Out-of-Regulation Indicator
• Fixed 1.8V, 2.5V, 3.3V, and 5V (MAX8881)
  Adjustable from 1.25V to 5V (MAX8880)
• Tiny 6-Pin SOT23 Package
• Thin 6-Pin TDFN Package

The MAX8880/MAX8881 are ultra-low supply current, low-dropout linear regulators, capable of delivering up to 200mA. They are designed for battery-powered applications where reverse battery protection and long battery life are critical.

These regulators' low 3.5µA supply current extends battery life in applications with long standby periods. Unlike PNP-based designs, a 2Ω PMOS device maintains ultra-low supply current throughout the entire operating range and in dropout. The parts are internally protected from output short circuits, reverse battery connection, and thermal overload. An internal power-OK (POK) comparator indicates when the output is out of regulation.

The MAX8880 output is adjustable from 1.25V to 5V using an external resistor-divider. The MAX8881 provides only factory-preset output voltages of 1.8V, 2.5V, 3.3V, or 5V (see Ordering Information in the full data sheet). The devices are available in 6-pin SOT23 and 6-pin TDFN packages.

Applications

• Battery-Powered Alarms
• CMOS Backup Power
• Handy Terminals
• PDAs
• Real-Time Clocks
• Remote Transmitters
• Smart Battery Packs/Chargers
• Smoke Detectors
