Analog Devices MAX77752 Product Info

• Highly Integrated
  • Three Buck Regulators
  • Integrated High-Accuracy Brownout Comparators
  • One Low-Dropout Linear Regulator
  • Low-Input Voltage
  • Two Dedicated Load Switch Controllers
  • One Inrush-Current Limiter, Configurable to be Load Switch 3 Controller Using OTP
  • Two External Regulator Enable Outputs
  • Voltage Monitor for Backup Power Control
• Highly Flexible and Configurable
  • I²C-Compatible Interface
  • Factory OTP Options Available
  • Flexible Power Sequencer
  • Configurable Sleep-State Control
• Small Size
  • 40-Pin, 5mm x 5mm x 0.8mm, 0.4mm Pitch TQFN
  • 70mm² Total Solution Size

The MAX77752 is a highly-integrated power management solution including three step-down converters, a low-dropout linear regulator, two external regulators enable outputs, two dedicated load switch controllers, and an inrush-current limiter which can be configured as a third load switch controller using OTP. The MAX77752 provides a combination of high-performance power management components, high-accuracy monitoring, and a customized top-level controller that results in an efficient, size optimized solution.

The 40-pin, 5mm x 5mm x 0.8mm, 0.4mm pitch TQFN package is ideal for space constrained applications.

Numerous factory programmable options allow the device to be tailored for many variations of the end application.

Applications

• Automation Systems
• Cameras
• Drones
• Gaming Consoles
• Handheld Devices
• Solid-State Drive Systems
