Analog Devices MAX17783C Product Info

• Reduces External Components and Total Cost
  • Internal Compensation Components
  • All-Ceramic Capacitors, Compact Layout
• Reduces Number of DC-DC Regulators to Stock
  • Wide 6V to 60V Input-Voltage Range
  • Adjustable Output Range from 0.9V up to 90% of V_IN
  • Delivers up to 2.5A Over the Temperature Range
  • 400kHz to 2.2MHz Adjustable Frequency with External Clock Synchronization
• Reduces Power Dissipation
  • 90.4% Peak Efficiency
  • 3.01μA Shutdown Current
  • Low I_q Mode for Enhanced Light-Load Efficiency
• Operates Reliably in Adverse Industrial Environments
  • Hiccup-Mode Overload Protection
  • Adjustable and Monotonic Startup with Prebiased Output Voltage
  • Built-In Output-Voltage Monitoring with Active-Low RESET
  • Programmable EN/UVLO Threshold
  • Complies with CISPR32(EN55032) Class B Conducted and Radiated Emissions
  • Overtemperature Protection
  • Wide -40°C to +125° C Ambient Operating Temperature Range/ -40°C to +150°C Junction Temperature Range

The Himalaya series of voltage regulator ICs, power modules, and chargers enable cooler, smaller, and simpler power supply solutions. The MAX17783C is a high-efficiency, high-voltage, Himalaya step-down DC-DC converter with an integrated high-side MOSFET operating over a wide input-voltage range of 6V to 60V. It can deliver up to 2.5A current, and generate output voltages from 0.9V up to 90% of V_IN. The device features internal compensation.

The MAX17783C device uses peak current-mode control architecture. The device operates in Low I_q mode at light loads to enable high efficiency. The MAX17783C offers a low minimum on-time that allows high switching frequencies and smaller solution sizes. The feedback-voltage regulation accuracy is ±1.6% over -40°C to +125°C. The MAX17783C is available in a compact 10-pin (3mm x 3mm) TDFN package. Simulation models are available.

Applications

• Industrial and Commercial Power Distribution
• General Purpose Point-of-Load
• Distributed Supply Regulation
• Base-Station Power Supplies
• Wall Transformer Regulation
• High-Voltage, Single-Board Systems
• Set Top Boxes
• Audio Power Supplies
• LED Displays
