Analog Devices MAX22508E Product Info

• High-Speed Operation Over Long Distances
  • Up to 50Mbps Data Rate
  • High Receiver Sensitivity
  • Wide Receiver Bandwidth
  • Symmetrical Receiver Thresholds
• Integrated Protection Increases Robustness
  • -15V to +15V Common Mode Range
  • ±15kV ESD Protection (Human Body Model)
  • ±7kV IEC 61000-4-2 Air-Gap ESD Protection
  • ±6kV IEC 61000-4-2 Contact Discharge ESD Protection
  • Withstands Over ±4kV EFT
  • Driver Outputs are Short-Circuit Protected
• Flexibility for Many Different Applications
  • 3V to 5.5V Supply Range
  • Low 5µA (max) Shutdown Current (MAX22507E)
  • Allows up to 200 Transceivers on the Bus
  • Available in a 10-pin µMAX Package (MAX22507E) and 8-pin SOIC Package (MAX22508E)
  • -40°C to +125°C Operating Temperature Range

The MAX22507E/MAX22508E ESD-protected RS-485/RS-422 full duplex transceivers are optimized for high-speed communication up to 50Mbps. These transceivers feature integrated hot-swap protection and a fail-safe receiver, ensuring a logic-high on the receiver output when input signals are shorted or open for longer than 10µs (typ). Additionally, a large receiver hysteresis improves noise rejection and signal integrity.

The MAX22507E/MAX22508E are designed to operate in harsh industrial environments and are optimized for robust communication in environments with high levels of electromagnetic interference (EMI).

The MAX22507E is available in a 10-pin µMAX package and the MAX22508E is available in an 8-pin SOIC package. µMAX is the Maxim-trademarked equivalent to the industry-standard MSOP package. Both transceivers operate over the -40°C to +125°C temperature range.

Applications

• Motion Control
• Encoder Interfaces
• Field Bus Networks
• Industrial Control Systems
• Backplane Busses
