• High Integration
  • Complete Display Power Solution from Automotive Battery
  • One High-Voltage 2.1A Buck Converter (5V or 3.3V)
  • One High-Voltage 100mA Low-I_Q Linear Regulator (3.3V)
  • One Low-Voltage 1.6A Buck Converter (3.3V, 1.8V, 1.2V, or 1.1V)
  • One Low-Voltage Linear Regulator (3.3V, 1.8V, 1.5V, or 1.0V)
    • MAX16923GTPB: 75mA
    • MAX16923GTPC/MAX16923GTPE: 175mA
    • All other variants: 180mA
  • Power-Good Outputs
• Integrated Watchdog Timer
• Robust and Low EMI
  • Programmable Switching Frequency
  • Internal Spread-Spectrum Oscillator
  • Slew-Rate Controlled Switching
  • Thermal Shutdown Protection
• Compact TQFN20 4mm x 4mm Package

The MAX16923 is a 4-channel power-management IC designed to accommodate the main rails used in modern automotive TFT displays. The MAX16923 and the MAX20069 TFT power supply and LED backlight driver combine to provide a two-chip solution to all automotive display power-supply requirements.

The MAX16923 integrates a high-voltage buck converter that transforms battery voltages into a 5V or 3.3V intermediate rail. In addition, a high-voltage, always-on, low-quiescent-current linear regulator supplies power at 3.3V.

The low-voltage section consists of a fully-integrated DC/DC converter and an LDO running off the intermediate rail. Section output power is available in several low-voltage combinations (see the Ordering Information table). In addition, an integrated watchdog timer guards against runaway code.

A single START control pin initiates the start-up sequence, thereby simplifying device control. The MAX16923's external pMOSFET control block allows battery voltage to be switched to a downstream device, such as a backlight boost converter.

The MAX16923 is available in a TQFN package and operates in the -40°C to 105°C temperature range.

Design Solution: PMIC Streamlines Automotive TFT-LCD Display Design ›

Applications

• Central Information Displays
• Infotainment Displays
• Instrument Clusters
