Analog Devices HMC745 Product Info

• Inputs terminated internally at 50 Ω
• Differential and single-ended operation
• Fast rise and fall times: 21/19 ps
• Low power consumption: 240 mW (typical)
• Programmable Differential
  Output voltage swing: 600 mV to 1200 mV
• Propagation delay: 95 ps
• Single supply: 3.3 V
• 16-terminal, ceramic 3 mm × 3 mm LCC package

The HMC745 is a XOR/XNOR gate function designed to support data transmission rates of up to 13 Gbps, and clock frequencies as high as 13 GHz. The HMC745 also features an output level control pin, VR, which permits loss compensation or signal level optimization.

All input and output signals to the HMC745 are terminated with 50 Ω to V_CC on-chip, and can be either ac-coupled or dc-coupled

Inputs or outputs can be connected directly to a 50 Ω V_CC terminated system, while dc blocking capacitors may be used if the terminating system is 50 Ω to ground. The HMC745 operates from a single 3.3 V dc supply, and is available in a ceramic, RoHS compliant, 3 mm × 3 mm LCC package.

Applications

• RF automatic test equipment (ATE) applications
• Broadband test and measurement
• Serial data transmission up to 13 Gbps
• Digital logic systems up to 13 GHz
