ADP1612

PRODUCTION

650 kHz /1.3 MHz Step-Up PWM DC-to-DC Switching Converter with 1.4 A Current Limit

Analog Devices ADP1612 Product Info

10 February 2026 5

Features

Current limit
1.4 A
Minimum input voltage
1.8 V
Pin-selectable 650 kHz or 1.3 MHz PWM frequency
Adjustable output voltage up to 20 V

Adjustable soft start
Undervoltage lockout
Thermal shutdown
8-lead MSOP

Part details & applications

The ADP1612/ADP1613 are step-up dc-to-dc switching con-verters with an integrated power switch capable of providing an output voltage as high as 20 V. With a package height of less than 1.1 mm, the ADP1612/ADP1613 are optimal for space-constrained applications such as portable devices or thin film transistor (TFT) liquid crystal displays (LCDs).

The ADP1612/ADP1613 operate in current mode pulse-width modulation (PWM) with up to 94% efficiency. Adjustable soft start prevents inrush currents when the part is enabled. The pin-selectable switching frequency and PWM current-mode architecture allow for excellent transient response, easy noise filtering, and the use of small, cost-saving external inductors and capacitors. Other key features include undervoltage lockout (UVLO), thermal shutdown (TSD), and logic controlled enable.

The ADP1612/ADP1613 are available in the lead-free 8-lead MSOP.

Applications

TFT LCD bias supplies

Portable applications

Industrial/instrumentation equipment
