ADH554S

RECOMMENDED FOR NEW DESIGNS

Aerospace GaAs Fundamental Mixer, 11 GHz – 18 GHz

Analog Devices ADH554S Product Info

10 February 2026 6

Features

High LO / RF Isolation: 40 dB
Low Conversion Loss: 9 dB
Wide IF Bandwidth: DC – 6 GHz
Passive Double Balanced Topology
Robust 1000V ESD, Class 1C
Hermetic SMT Package, 25mm²

Part details & applications

The ADH554S is a passive double balanced mixer that can be used as an upconverter or downconverter between 11 and 18 GHz. The miniature monolithic mixer is fabricated in a GaAs MESFET process, and requires no external components or matching circuitry. The ADH554S provides excellent LO to RF and LO to IF isolation due to optimized balun structures.

Applications

Microwave Radio
VSAT
Military & Space
Communications, Radar & EW
