ADG2436

RECOMMENDED FOR NEW DESIGNS

0.5 Ω RON, ±15 V, +12 V, ±5 V, and +5 V/−12 V, Dual SPDT Switch

Analog Devices ADG2436 Product Info

10 February 2026 5

Features

Low R_ON: 0.5 Ω
High continuous current of up to 847 mA
Flat R_ON across signal range: 0.003 Ω
THD of −108 dB at 1 kHz
Improved balance between on resistance and on capacitance
- Low R_ON (0.5 Ω) and C_ON (100 pF)

1.8 V, 3.3 V, and 5 V logic compatibility
16-lead, 4 mm × 4 mm LFCSP
- Pin to pin compatible with the ADG1436
Fully specified at ±15 V, +12 V, ±5 V, and +5 V/−12 V
Operational with asymmetric power supplies
V_SS to V_DD − 2 V analog signal range

Part details & applications

The ADG2436 is an analog multiplexer containing two independently selectable single-pole, double throw (SPDT) switches. An EN input is used to disable all of the switches. For use in multiplexer applications, both switches exhibit break-before-make switching action.

Each channel conducts equally well in both directions when on, and each switch has an input signal range that extends from V_SS to V_DD − 2 V. When switches are disabled, the signal levels up to the supplies are blocked.

The digital inputs are compatible with 5 V, 3.3 V, and 1.8 V logic inputs without the requirement for a separate digital logic supply pin.

The on-resistance profile is exceptionally flat over the full analog input range, which ensures good linearity and low distortion when switching audio signals.

APPLICATIONS

Automatic test equipment
Data acquisition
Instrumentation
Avionics
Audio and video switching
Communication systems
Relay replacement
