ADF7030

NOT RECOMMENDED FOR NEW DESIGNS

High Performance, Low Power, 169MHz ISM Band, Radio Transceiver IC

Analog Devices ADF7030 Product Info

10 February 2026 6

Features

RF frequency range: 169.4 MHz to 169.6 MHz
Modulation: 2GFSK, 4GFSK
Data rates:
2GFSK: 2.4 kbps and 4.8 kbps
4GFSK: 6.4 kbps (Tx only)
1nA sleep current

Receiver performance
97 dB blocking at ±10 MHz offset
66 dB adjacent channel rejection
−122 dBm sensitivity
See data sheet for additional features

Part details & applications

The ADF7030 is a low power, high performance, integrated radio transceiver supporting narrowband operation in the 169.4MHz to 169.6MHz ISM bands. The ADF7030 supports transmit and receive operation at 2.4kbps and 4.8kbps using 2GFSK modulation and transmit operation at 6.4kbps using 4GFSK modulation.

The ADF7030 features an on-chip ARM^® Cortex^®-M0 processor that performs radio control and packet management.

Applications

Wireless M-Bus Mode N (EN 13757-4)
Smart metering
Social alarms
Active tag asset tracking
