Analog Devices ADE7979 Product Info

The ADE7979 is a high accuracy, 3-phase, digital metrology engine with flexible serial interfaces and three flexible pulse outputs (CF1, CF2, and CF3). The device takes in four sigma-delta (Σ-Δ) analog-to-digital converter (ADC) bit streams and performs all essential energy metering functions including reactive power and rms to create a polyphase energy metering application using shunt current sensors. A complete metrology system requires the ADE7979, up to four ADE9322B Σ-Δ ADC ICs, external isolation, and a power supply of 3.3 V. The power supply required to power the ADE7979 is 3.3 V and must be isolated from the Σ-Δ ADC ICs.

The ADE7979 incorporates all signal processing required to perform total (fundamental and harmonic) active, reactive, and apparent energy measurement and rms calculations, as well as fundamental only active and reactive energy measurement and rms calculations. A fixed function digital signal processor (DSP) executes this signal processing.

The ADE7979 measures the active, reactive, and apparent energy in 3-phase configurations that include delta and wye services that can both be used with either three or four wires. The ADE7979 provides system calibration features for each phase, gain calibration, and optional offset correction. Phase compensation is also available on the device but is not necessary because the currents are sensed using shunts. The CF1, CF2, and CF3 pulse outputs provide a wide selection of power information that includes the sum of the current rms values, fundamental active and reactive powers, and total active, reactive, and apparent powers.

The ADE7979 incorporates power quality measurements that include short duration low or high voltage detection, short duration high current variations, line voltage period measurement, and angles between phase voltages and currents.

Either serial peripheral interface (SPI) or I²C interface can be
