ADAQ8092

RECOMMENDED FOR NEW DESIGNS

14-Bit, 105 MSPS, μModule

Analog Devices ADAQ8092 Product Info

10 February 2026 6

Features

Dual-channel simultaneously sampling ADC
Integrated differential amplifier/ADC driver
Single-ended to differential conversion
Package footprint, 7 mm × 6 mm, 72-ball CSP_BGA
6× footprint reduction vs. discrete solution

On-chip reference circuitry with VOCM generation
CMOS, DDR CMOS, or DDR LVDS outputs
Optional data output randomizer
Optional clock duty-cycle stabilizer
Shutdown and nap modes
Serial SPI port for configuration

Part details & applications

The ADAQ8092 is a 14-bit, 105 MSPS, high-speed dual-channel data acquisition (DAQ) μModule^® solution. The device incorporates signal conditioning, an analog-to-digital (ADC) driver, a voltage reference, and an ADC in a single package via system in package (SiP) technology. μModule solutions simplify the development of high-speed data acquisition systems by transferring the design burden, component selection, optimization, and layout from the designer to the device. The ADAQ8092 enables a 6× footprint reduction.

Built-in power supply decoupling capacitors enhance power supply rejection performance, making it a robust DAQ solution. The operating temperature range of the ADAQ8092 is −40°C to +105°C.

APPLICATIONS

Communications
Cellular base stations
