• SNR = 79.9 dBFS at 16 MHz (V_REF = 1.4 V)
• SNR = 78.1 dBFS at 64 MHz (V_REF = 1.4 V)
• SFDR = 86 dBc to Nyquist (V_REF = 1.4 V)
• JESD204B Subclass 1 coded serial digital outputs
• Flexible analog input range: 2.0 V p-p to 2.8 V p-p
• 1.8 V supply operation
• Low power: 197 mW per channel at 125 MSPS (two lanes)
• DNL = ±0.6 LSB (V_REF = 1.4 V)
• INL = ±4.5 LSB (V_REF = 1.4 V)
• 650 MHz analog input bandwidth, full power
• Serial port control

  • Full chip and individual channel power-down modes
  • Built-in and custom digital test pattern generation
  • Multichip sync and clock divider
  • Standby mode

The AD9656 is a quad, 16-bit, 125 MSPS analog-to-digital converter (ADC) with an on-chip sample and hold circuit designed for low cost, low power, small size, and ease of use. The device operates at a conversion rate of up to 125 MSPS and is optimized for outstanding dynamic performance and low power in applications where a small package size is critical.

The ADC requires a single 1.8 V power supply and LVPECL-/CMOS-/LVDS-compatible sample rate clock for full performance operation. An external reference or driver components are not required for many applications.

Individual channel power-down is supported and typically consumes less than 14 mW when all channels are disabled. The ADC contains several features designed to maximize flexibility and minimize system cost, such as a programmable output clock, data alignment, and digital test pattern generation. The available digital test patterns include built-in deterministic and pseudo-random patterns, along with custom user-defined test patterns entered via the serial port interface (SPI).

The AD9656 is available in an RoHS compliant, nonmagnetic, 56-lead LFCSP. It is specified over the −40°C to +85°C industrial temperature range.

Product Highlights

1. It has a small footprint. Four ADCs are contained in a small, 8 mm × 8 mm package.
2. An on-chip phase-locked loop (PLL) allows users to provide a single ADC sampling clock; the PLL multiplies the ADC sampling clock to produce the corresponding JESD204B data rate clock.
3. The configurable JESD204B output block supports up to 8.0 Gbps per lane.
4. JESD204B output block supports one, two, and four lane configurations.
5. Low power of 198 mW per channel at 125 MSPS, two lanes.
6. The SPI control offers a wide range of flexible features to meet specific syste
