TPUL2G122-Q1

ACTIVE

Texas Instruments TPUL2G122-Q1 Product Info

1 April 2026 0

Number of channels	2
Supply voltage (min) (V)	1.5
Supply voltage (max) (V)	5.5
Technology family	TPUL
Input type	Schmitt-Trigger
Output type	Push-Pull
Supply current (µA)	2
IOL (max) (mA)	12
IOH (max) (mA)	-12
Features	Balanced outputs, High speed (tpd 10-50ns), Over-voltage tolerant inputs, Partial power down (Ioff), Retriggerable
Operating temperature range (°C)	-40 to 125
Rating	Automotive

WQFN (BQB)-16-8.75 mm² 3.5 x 2.5

AEC-Q100 qualified for automotive applications:
- Device temperature grade 1: -40°C to +125°C
- Device HBM ESD classification level 2
- Device CDM ESD classification level C4B
Available in wettable flank QFN package
RC configurable from 1µs to 860ms (VCC = 3.3V)
For longer pulse widths, TI recommends TPUL2T323-Q1
10% maximum pulse width variation
Wide operating range from 1.5V to 5.5V
Inputs accept voltages up to 5.5V
Schmitt-trigger architecture on all inputs

AEC-Q100 qualified for automotive applications:
- Device temperature grade 1: -40°C to +125°C
- Device HBM ESD classification level 2
- Device CDM ESD classification level C4B
Available in wettable flank QFN package
RC configurable from 1µs to 860ms (VCC = 3.3V)
For longer pulse widths, TI recommends TPUL2T323-Q1
10% maximum pulse width variation
Wide operating range from 1.5V to 5.5V
Inputs accept voltages up to 5.5V
Schmitt-trigger architecture on all inputs
