• Qualified for automotive applications
• AEC-Q100 qualified with the following results:
  • Device temperature grade 3: –40°C to 85°C ambient operating temperature range
  • Device HBM ESD classification level H2
  • Device CDM ESD classification level C3B
• Supports pixel rates up to 165 MHz (including 1080p and WUXGA at 60 Hz)
• Digital visual interface (DVI) specification compliant⁽¹⁾
• True-Color, 24-bit/pixel, 16.7M colors at 1 or 2 pixels per clock
• Laser-trimmed internal termination resistors for optimum fixed impedance matching
• Skew tolerant up to one pixel-clock cycle
• 4× oversampling
• Reduced power consumption: 1.8-V core operation with 3.3-V I/Os and supplies⁽²⁾
• Reduced ground bounce using time-staggered pixel outputs
• Low noise and good power dissipation using TI PowerPAD™ packaging
• Advanced technology using TI 0.18-µm EPIC-5™ CMOS process
• TFP401A-Q1 Incorporates HSYNC Jitter Immunity⁽³⁾

⁽¹⁾The TFP401A-Q1 device incorporates additional circuitry to create a stable HSYNC from DVI transmitters that introduce undesirable jitter on the transmitted HSYNC signal.

⁽²⁾The TFP401A-Q1 device has an internal voltage regulator that provides the 1.8-V core power supply from the external 3.3-V supplies.

⁽³⁾The Digital Visual Interface Specification, DVI, is an industry standard developed by the Digital Display Working Group (DDWG) for high-speed digital connection to digital displays. The TFP401A-Q1 is compliant with the DVI Specification Rev. 1.0.
