ACTIVE
Rating |
Catalog |
VO (V) |
1.25, 2.048, 2.5, 3, 3.3, 4.096 |
Temp coeff (max) (ppm/°C) |
75 |
Initial accuracy (max) (%) |
0.2 |
Iout/Iz (max) (mA) |
25 |
Vin (min) (V) |
1.8 |
Vin (max) (V) |
5.5 |
Iq (typ) (mA) |
0.042 |
LFN 0.1 to 10 Hz (typ) (µVPP) |
14 |
Operating temperature range (°C) |
-40 to 125 |
SOT-23 (DBZ)-3-6.9204 mm² 2.92 x 2.37
The REF30 is a precision, low-power, low-dropout voltage, reference family available in a tiny 3-pin SOT-23 package. REF30E is the enhanced performance version of REF30 family which is designed for precision applications. The REF30E offers improved temperature drift and initial accuracy while operating at a lower quiescent current of 25µA.
The low power consumption and the improved precision make the REF30E very attractive for loop-powered industrial applications such as pressure and temperature transmitter and battery-powered applications. The REF30/REF30E is specified over the extended industrial temperature range of –40°C to +125°C. The REF30 is easy to use in intrinsically safe and explosion-proof applications because the REF30 does not require a load capacitor to be stable.
