ACTIVE
Number of channels |
2 |
Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V) |
5.5 |
Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V) |
2.2 |
Vos (offset voltage at 25°C) (max) (mV) |
1 |
Offset drift (typ) (µV/°C) |
0.32 |
Input bias current (max) (pA) |
10 |
GBW (typ) (MHz) |
5.5 |
Slew rate (typ) (V/µs) |
2 |
Rail-to-rail |
In, Out |
Iq per channel (typ) (mA) |
0.76 |
Vn at 1 kHz (typ) (nV√Hz) |
7.5 |
CMRR (typ) (dB) |
90 |
Rating |
Catalog |
Operating temperature range (°C) |
-40 to 125 |
Iout (typ) (A) |
0.03 |
Architecture |
CMOS |
Input common mode headroom (to negative supply) (typ) (V) |
-0.1 |
Input common mode headroom (to positive supply) (typ) (V) |
0.1 |
Output swing headroom (to negative supply) (typ) (V) |
0.01 |
Output swing headroom (to positive supply) (typ) (V) |
-0.01 |
THD + N at 1 kHz (typ) (%) |
0.00027 |
SOIC (D)-8-29.4 mm² 4.9 x 6
All trademarks are the property of their respective owners.
The OPA377 family of operational amplifiers are wide-bandwidth CMOS amplifiers that provide very low noise, low input bias current, and low offset voltage while operating on a low quiescent current of 0.76mA (typ).
The OPA377 op amps are optimized for low-voltage, single-supply applications. The exceptional combination of ac and dc performance make them ideal for a wide range of applications, including small signal conditioning, audio, and active filters. In addition, these parts have a wide supply range with excellent PSRR, making them attractive for applications that run directly from batteries without regulation.
The OPA377 is available in the SC70-5, SOT23-5, and SO-8 packages. The dual OPA2377 is offered in the SO-8 and MSOP-8, and the quad OPA4377 in the TSSOP-14 packages. All versions are specified for operation from –40°C to +125°C.
