ACTIVE
Number of channels |
2 |
Vrwm (V) |
24 |
Bi-/uni-directional |
Uni-Directional |
Package name |
SOT-23-3 |
Peak pulse power (8/20 μs) (max) (W) |
210 |
IO capacitance (typ) (pF) |
4.5 |
IEC 61000-4-2 contact (±V) |
30000 |
IEC 61000-4-5 (A) |
5.7 |
Clamping voltage (V) |
31 |
Interface type |
CAN, GPIO, LIN |
Breakdown voltage (min) (V) |
24.8 |
IO leakage current (max) (nA) |
5.5 |
Rating |
Catalog |
Operating temperature range (°C) |
-55 to 150 |
SOT-23 (DBZ)-3-6.9204 mm² 2.92 x 2.37
The MMBZ30VCL is a dual channel unidirectional or single channel bidirectional ESD in a common cathode configuration. The devices low capacitance and low leakage features enable use in high speed applications. The low dynamic resistance allows low clamping voltage to help protect systems against transient events.
The MMBZ30VCL is packaged in the SOT-23, providing two channels of robust transient protection in one space-efficient form factor.
