ACTIVE
Number of channels |
1 |
Output type |
Open-collector, Open-drain |
Propagation delay time (µs) |
4 |
Vs (max) (V) |
15 |
Vs (min) (V) |
2.7 |
Rating |
Catalog |
Iq per channel (typ) (mA) |
0.007 |
Vos (offset voltage at 25°C) (max) (mV) |
5 |
Rail-to-rail |
In |
Operating temperature range (°C) |
-40 to 85 |
Input bias current (±) (max) (nA) |
0.0004 |
VICR (max) (V) |
15.2 |
VICR (min) (V) |
-0.2 |
SOIC (D)-8-29.4 mm² 4.9 x 6
The LM7221 is a micropower CMOS comparator available in the space saving 5-Pin SOT-23 package. This makes this comparator ideal for space and weight critical designs. The LMC7221 is also available in the 8-Pin SOIC package. The LMC7221 is supplied in two offset voltage grades, 5mV and 15mV.
The open drain output can be pulled up with a resistor to a voltage which can be higher or lower than the supply voltage—this makes the part useful for mixed voltage systems.
For a tiny comparator with a push-pull output, please see the LMC7211 data sheet.
