ACTIVE
Number of channels |
2 |
Output type |
Push-Pull |
Propagation delay time (µs) |
4 |
Vs (max) (V) |
15 |
Vs (min) (V) |
2.7 |
Rating |
Catalog |
Iq per channel (typ) (mA) |
0.006 |
Vos (offset voltage at 25°C) (max) (mV) |
5 |
Rail-to-rail |
In |
Operating temperature range (°C) |
-40 to 85 |
Input bias current (±) (max) (nA) |
0.0004 |
VICR (max) (V) |
15.2 |
VICR (min) (V) |
-0.2 |
SOIC (D)-8-29.4 mm² 4.9 x 6
The LMC6762 is an ultra low power dual comparator with a maximum supply current of 10 µA. It is designed to operate over a wide range of supply voltages, from 2.7V to 15V. The LMC6762 has ensured specifications at 2.7V to meet the demands of 3V digital systems.
The LMC6762 has an input common-mode voltage range which exceeds both supplies. This is a significant advantage in low-voltage applications. The LMC6762 also features a push-pull output that allows direct connections to logic devices without a pull-up resistor.
A quiescent power consumption of 50 µW (@ V+ = 5V) makes the LMC6762 ideal for applications in portable phones and hand-held electronics. The ultra-low supply current is also independent of power supply voltage. Ensured operation at 2.7V and a rail-to-rail performance makes this device ideal for battery-powered applications.
Refer to the LMC6772 datasheet for an open-drain version of this device.
