0
ACTIVE
Number of channels |
2 |
Output type |
Open-collector, Open-drain |
Propagation delay time (µs) |
1.3 |
Vs (max) (V) |
32 |
Vs (min) (V) |
2 |
Rating |
Automotive |
Iq per channel (typ) (mA) |
0.4 |
Vos (offset voltage at 25°C) (max) (mV) |
7 |
Rail-to-rail |
In to V- |
Operating temperature range (°C) |
-40 to 125 |
Input bias current (±) (max) (nA) |
50 |
VICR (max) (V) |
30.5 |
VICR (min) (V) |
0 |
SOIC (D)-8-29.4 mm² 4.9 x 6
The LM393B and LM2903B devices are the next generation versions of the industry-standard LM393 and LM2903 comparator family. These next generation B-version comparators feature lower offset voltage, higher supply voltage capability, lower supply current, lower input bias current, lower propagation delay, and improved 2 kV ESD performance and input ruggedness through dedicated ESD clamps. The LM393B and LM2903B can drop-in replace the LM293, LM393 and LM2903, for both "A" and "V" grades.
All devices consist of two independent voltage comparators that are designed to operate from a single power supply over a wide range of voltages. Quiescent current is independent of the supply voltage.
