DLP991U
  • DLP991U
  • DLP991U

DLP991U

ACTIVE

0.99-inch 4K high-speed DLP® digital micromirror device (DMD)

Texas Instruments DLP991U Product Info

1 April 2026 3

Parameters

Illumination wavelength (min) (nm)

400

Illumination wavelength (max) (nm)

700

Pattern rate, binary (max) (Hz)

12400

Array diagonal (in)

0.99

Micromirror array size

4096 x 2176

Micromirror pitch (mm)

0.0054

Micromirror array orientation

Corner

Rating

Catalog

Operating temperature range (°C)

45 to 90

Package

DLP-TYPEA.9 (FLV)-321-1777.4656 mm² 42.16 x 42.16

Features

  • High resolution 4096 × 2176 micromirror array
    • > 8.9 million micromirrors
    • 5.4µm micromirror pitch
    • 0.99" micromirror array diagonal
    • ±12° micromirror tilt relative to flat S
    • Designed for corner illumination
    • Integrated micromirror driver circuitry
  • Designed for visible light use (400nm to 800nm)
    • 97% window transmission (single pass, through two window surfaces)
    • 89% micromirror reflectivity
    • 79% average photopic weighted diffraction and 80% unweighted (410nm–800nm) efficiency (f/2.4) per photopic luminous efficiency—CIE 086-1990
    • 90% on-state array fill factor
  • High resolution 4096 × 2176 micromirror array
    • > 8.9 million micromirrors
    • 5.4µm micromirror pitch
    • 0.99" micromirror array diagonal
    • ±12° micromirror tilt relative to flat S
    • Designed for corner illumination
    • Integrated micromirror driver circuitry
  • Designed for visible light use (400nm to 800nm)
    • 97% window transmission (single pass, through two window surfaces)
    • 89% micromirror reflectivity
    • 79% average photopic weighted diffraction and 80% unweighted (410nm–800nm) efficiency (f/2.4) per photopic luminous efficiency—CIE 086-1990
    • 90% on-state array fill factor

Description

Featuring over 8.9 million micromirrors, the high-resolution DLP991U digital micromirror device (DMD) is a spatial light modulator (SLM) that modulates the amplitude, direction, or phase of incoming light. This advanced light control technology has numerous applications in the industrial, medical, and consumer markets. The streaming nature of the DLP991U and its DLPC964 controller make it ideally suited for exceptionally high-speed continuous data streaming for direct imaging (LDI) applications. The DMD enables large 3D print build sizes and ultra-fine resolutions for various 3D printing applications. The high resolution provides a direct benefit to the scanning of larger objects in 3D machine vision applications.
