DLP160CP
  • DLP160CP

DLP160CP

ACTIVE

0.16-inch nHD DLP® digital micromirror device (DMD)

Texas Instruments DLP160CP Product Info

1 April 2026 0

Parameters

Display resolution (max)

nHD (640x360)

System brightness (max) (lm)

120

Input frame rate (max) (Hz)

360

Array diagonal (in)

0.16

Micromirror array size

640x360

Micromirror pitch (mm)

0.0054

Chipset family

DLP160CP, DLPA2000, DLPA2005, DLPC3421

Rating

Catalog

Operating temperature range (°C)

0 to 70

Package

DLP-S248 (FQT)-42-66.5483 mm² 13.39 x 4.97

Features

  • Ultra-compact 0.16-inch (3.965mm) diagonal micromirror array
    • nHD Configuration—Display 640x360 resolution on-screen
    • HD Configuration—Display 1280x720 resolution on-screen
    • 5.4µm micromirror pitch
    • 17° micromirror tilt (relative to a flat surface)
    • Side illumination for optimal efficiency and optical engine size
    • Polarization-independent aluminum micromirror surface
  • 4-bit SubLVDS input data bus
  • Dedicated DLPC3421 display controller and DLPA2000, DLPA2005, or DLPA3000 PMIC/LED driver for reliable operation
  • Ultra-compact 0.16-inch (3.965mm) diagonal micromirror array
    • nHD Configuration—Display 640x360 resolution on-screen
    • HD Configuration—Display 1280x720 resolution on-screen
    • 5.4µm micromirror pitch
    • 17° micromirror tilt (relative to a flat surface)
    • Side illumination for optimal efficiency and optical engine size
    • Polarization-independent aluminum micromirror surface
  • 4-bit SubLVDS input data bus
  • Dedicated DLPC3421 display controller and DLPA2000, DLPA2005, or DLPA3000 PMIC/LED driver for reliable operation

Description

The DLP160CP digital micromirror device (DMD) is a digitally controlled micro-opto-electromechanical system (MOEMS) spatial light modulator (SLM). When coupled to an appropriate optical system, the DLP160CP DMD displays a crisp and high-quality image or video. DLP160CP is part of the chipset comprising the DLP160CP DMD and DLPC3421 controller. This chipset is also supported by the DLPA2000, DLPA2005, and DLPA3000 (HD configuration only) PMIC/LED driver. The compact physical size of the DLP160CP is well-suited for portable equipment where a small form factor and low power are important. The compact DLP160CP DMD coupled with the controller and PMIC/LED driver provides a complete system solution that enables a small form factor, low power, and high image-quality displays.

The DLP160CP digital micromirror device (DMD) is a digitally controlled micro-opto-electromechanical system (MOEMS) spatial light modulator (SLM). When coupled to an appropriate optical system, the DLP160CP DMD displays a crisp and high-quality image or video. DLP160CP is part of the chipset comprising the DLP160CP DMD and DLPC3421 controller. This chipset is also supported by the DLPA2000, DLPA2005, and DLPA3000 (HD configuration only) PMIC/LED driver. The compact physical size of the DLP160CP is well-suited for portable equipment where a small form factor and low power are important. The compact DLP160CP DMD coupled with the controller and PMIC/LED driver provides a complete system solution that enables a small form factor, low power, and high image-quality displays.
